Poppet Valve

3/2 X 5/2 Convertible Single Solenoid Directional Control Namur Poppet Valve (Monostable) - DCP Series

Valve Specifications
Type:

3/2 - 5/2

Design:

Internal Pilot Operated Poppet Valve

Port Size:

In / Exhaust - ¼" BSP & Out - Namur Hole Pattern (Available in NPT)

Media:

Compressed Air (Filtered & Lubricated)

Working Pressure Range:

2-10

Orifice:

7mm

Ambient/Medium Temperature:

5°C - 60°C

Materials of Construction:

Aluminium, Nitrile, Polymer, Brass

Flow Factor:

18 kv (LPM of Water @ 1 bar ΔP)

Coil Specification
Operating Voltage & Power Consumption:
24AC110AC230AC12DC24DC
9W9W9W10W11W
Coil Features:

High Reliability Unaffected by Voltage Surges. Easy coil changes coil lockable in 4X90 position or freely movable in between as required.

Coil Housing:

Epoxy square coil, Metallic round enclosure, IP-67 Flameproof enclosure, IP-68 Weatherproof enclosure.

More Information
Whatsapp Inquiry
Download PDF
  • Features
  • Port Connection
  • Dimension Drawing

Fetaures

  • Fast response time 1000 cycle/min.
  • Manual override.
  • 10 Million cycle tested
  • Lubrication not essential

1 - Input, 2/4 - Output, 3/5 - Exhaust

Model No. Coil Type Function Symbol
DCP-F1RET070 AC Single Solenoid Spring Return
DCP-F1RFT070 DC



Dimension Drawing (All dimensions in mm)
